Archer C58
AC1350 Wireless Dual Band Router
- The Advanced 802.11ac Wi-Fi gets your home network revolutionized
- Concurrent 2.4GHz 450Mbps and 5GHz 867Mbps dual band Wi-Fi connections
- Three high gain external antennas provide strong Wi-Fi signals
- Support advanced functions like Parental Control and Guest Network
- Tether app ensures an easy router management in your palm
Perfect Wi-Fi Entertainment is Yours
AC1350 Wireless Dual Band Router

Your Home Network Revolutionized
The Archer C58 comes with the brand new Wi-Fi standard – 802.11ac, widely compatible with both wireless AC and wireless N devices and three times faster than previous wireless N speeds. With this cutting edge technology, the Archer C58 offers you faster, stronger and more capable Wi-Fi. Simply put: a revolutionized network experience on all your devices.
Lightning Wi-Fi Powers Perfect Entertainment
The Archer C58 provides your entire home with simultaneous dual band Wi-Fi connections. The strong and stable 2.4GHz wireless band with 450Mbps Wi-Fi speed is perfect for sending emails, browsing the web or listening to music. Meanwhile, the 5GHz wireless band provides up to 867Mbps Wi-Fi speed for latency-sensitive entertainment so you can stream HD video, play online games and hold video chats all at the same time, without delay.

867Mbps 450Mbps
5GHz 2.4GHz









Strong Signal, Great Coverage
The Archer C58’s three high performance external antennas ensure full home Wi-Fi coverage. Combined with a dual band wireless network, its increased stability and range means you will no longer suffer from weak, dropped connections.
Easy Parental Control
Supervise children and staff with responsible access, controlled by parents or administrators. Use URL blocking to easily set up a black or white list and limit the level of web access.
Guest Network Access
Allow guests to join your Wi-Fi network, while protecting your privacy. Make sharing easy, maintain security.
Easy Setup and Management
Set up the Archer C58 in minutes thanks to its intuitive web interface. Configuration is also in the palm of your hands with TP-LINK’s powerful app, Tether, the easiest way to access and manage your router through your smartphone.
Learn more about Web UI >Learn more about Tether App >
WIRELESS |
|
---|---|
Standards and Protocols | Wi-Fi 5 IEEE 802.11ac/n/a 5 GHz IEEE 802.11n/b/g 2.4 GHz |
WiFi Speeds | AC1200 5 GHz: 867 Mbps (802.11ac) 2.4 GHz: 300 Mbps (802.11n) |
WiFi Range | 2 Bedroom Houses 3× Fixed Antennas Multiple antennas form a signal-boosting array to cover more directions and large areas |
WiFi Capacity | Medium Dual-Band Allocate devices to different bands for optimal performance |
Working Modes | Router Mode Access Point Mode |
SECURITY |
|
---|---|
Network Security | SPI Firewall Access Control IP & MAC Binding Application Layer Gateway |
Guest Network | 1× 5 GHz Guest Network 1× 2.4 GHz Guest Network |
VPN Server | IPSec OpenVPN PPTP |
WiFi Encryption | WEP WPA WPA2 WPA/WPA2-Enterprise (802.1x) |
HARDWARE FEATURES |
|
---|---|
Interface | 4 10/100Mbps LAN Ports 1 10/100Mbps WAN Port |
Button | WPS/Reset Button Wireless On/Off Switch Power On/Off Button |
External Power Supply | 12VDC/1A |
Dimensions ( W x D x H ) | 8.9 × 5.8 × 1.3 in. (225×148×33 mm) |
Antenna | Three 5dBi external antennas |
HARDWARE |
|
---|---|
Processor | Single-Core CPU |
Ethernet Ports | 1× 10/100 Mbps WAN Port 4× 10/100 Mbps LAN Ports |
Buttons | Wi-Fi On/Off Button Power On/Off Button WPS/Reset Button |
Power | 12 V ⎓ 1 A |
WIRELESS FEATURES |
|
---|---|
Wireless Standards | IEEE 802.11ac/n/a 5GHz IEEE 802.11b/g/n 2.4GHz |
Wireless Speeds | 450Mbps(2.4GHz) 867Mbps(5GHz) |
Frequency | 2.4-2.5GHz 5.15-5.25GHz |
Wireless Modes | Wireless Router WDS(Four Address) WDS(AP+APC) |
Wireless Security | WEP WPA\WPA2 WPA-PSK\WPA2-PSK Wireless MAC Filter |
Transmission Power | 13.5dBm Max(2.4GHz) 17dBm Max(5GHz) |
SOFTWARE FEATURES |
|
---|---|
Quality of Service | WMM, Bandwidth Control |
WAN Type | Dynamic IP/Static IP/PPPoE/ BigPond/ /L2TP(Dual Access) /PPTP(Dual Access) |
Management Features | Access Control Local Management Remote Management |
DHCP | DHCP Server DHCP Client DHCP Client Address Reservatio |
VPN Pass-Through | PPTP L2TP IPSec(AH Head) IPSec(ESP Head) |
Access Control | Parental Control Local Management Control Host List Access Schedule Rule Management |
Protocols | IPv4 IPv6 |
Guest Network | 2.4GHz guest network 5GHz guest network |
SOFTWARE |
|
---|---|
Protocols | IPv4 IPv6 |
Parental Controls | URL Filtering Time Controls |
WAN Types | Dynamic IP Static IP PPPoE PPTP L2TP |
Quality of Service | QoS by Device |
NAT Forwarding | Virtual Server Port Forwarding Port Triggering DMZ UPnP |
IPTV | IGMP Proxy IGMP Snooping Bridge Tag VLAN |
DHCP | Address Reservation DHCP Client List Server |
DDNS | NO-IP DynDNS |
Management Features | Tether App Webpage Check Web Emulator> |
OTHER |
|
---|---|
System Requirements | Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser Cable or DSL Modem (if needed) Subscription with an internet service provider (for internet access) |
Certifications | FCC, CE, RoHS |
Environment | Operating Temperature: 0℃~40℃ (32℉ ~104℉) Storage Temperature: -40℃~70℃ (-40℉ ~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
TEST DATA |
|
---|---|
WiFi Transmission Power | CE EIRP: <20dBm(2.4GHz) <23dBm(5GHz) FCC: <30dBm(2.4GHz & 5GHz) |
WiFi Reception Sensitivity | 5GHz: 11a 6Mbps:-93dBm;11a 54Mbps:-78dBm; 11ac HT20 mcs8:69dBm;11ac HT40 mcs9:-65dBm; 11ac HT80 mcs9:-62dBm; 2.4GHz: 11g 54Mbps:-78dBm; 11n HT20 mcs7:-74dBm; 11n HT40 mcs7:-71dbm |
PHYSICAL |
|
---|---|
Dimensions (W×D×H) | 8.9 × 5.8 × 1.3 in (225 × 148 × 33 mm) |
Package Content | Wi-Fi Router Archer C58 Power Adapter RJ45 Ethernet Cable Quick Installation Guide |
OTHERS |
|
---|---|
Certification | CE, RoHS |
Package Content | AC1350 Wireless Dual Band Router Archer C58 Power supply unit Ethernet Cable Quick Installation Guide |
Environment | Operating Temperature: 0℃~40 ℃ (32 ℉~104℉) Storage Temperature: -40℃~70 ℃ (-40 ℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
Operating System | Microsoft Windows XP/Vista/7/8/8.1/10 MAC OS, NetWare, UNIX or Linux |
