Deco S4

New

AC1200 Whole Home Mesh WiFi System

  • Whole Home Coverage: Deco uses a system of units to achieve seamless whole-home Wi-Fi coverage up to 3,800 sq.ft.— eliminate weak signal areas once and for all! And if that’s not enough, simply add more Decos to the network anytime to increase coverage.
  • TP-Link Mesh: With advanced Deco Mesh Technology, units work together to form a unified network with a single network name. Devices automatically switch between Decos as you move through your home for the fastest possible speeds.
  • Fast Dual-Band WiFi: Deco S4 provides fast and stable connections with speeds of up to 1167 Mbps and works with all internet service providers (ISP) and modems.
  • Connect More Devices: Deco can handle traffic from even the busiest of networks, providing lag-free connections for up to 75 devices.
  • Parental Controls: Parental Controls limit online time and block inappropriate websites according to unique profiles created for each family member.
  • Easy Setup: Setup is easier than ever with the Deco app there to walk you through every step.

Fast. Stable. Everywhere.

Whole Home Mesh WiFi System
AC1200 Dual-Band WiFi

Deco S4



A New Way to WiFi

Deco Mesh technology gives you a better WiFi experience in all directions with faster WiFi speeds and a strong WiFi signal to cover your whole home.

WiFi Dead-Zone Killer

Get Deco S4 for a strong WiFi signal in every corner of your home up to 3,800 sq.ft (2-pack). Wireless connections and optional Ethernet backhaul work together to link Deco units, providing even faster network speeds and truly seamless coverage. Want more coverage? Simply add another Deco.

Ranch-Style Home
Multi-Story Home
L-Shaped Home
2.4 GHz wireless connection 5 GHz wireless connection Optional Gigabit Ethernet Backhaul

Seamless Roaming with One WiFi Name

Deco units work together to form one unified network with one single SSID. Your phone or tablet automatically connects to the fastest Deco as you move through your home, creating a truly seamless WiFi experience.

  •
  •

No More Buffering

Deco S4 provides a lag-free connection to up to 75 devices. A fast networking experience is guaranteed for all devices, and all applications from surfing, downloading, streaming to gaming.

Dual Band Speeds up to 1200 Mbps

5 GHz   867 Mbps
2.4 GHz   300 Mbps
connections for up to 75 devices
1080P Streaming
720P Streaming
Web Browsing
Smart Home Devices
IP Camera Streaming
4K Streaming
High-speed Downloading
Smooth Operation for Multiple Applications
*Testing of multiple applications conducted by TP-Link in December 2018.

2-in-1 Router and Access Point Modes

Flexible and multifunctional, the Deco S4 includes a variety of features allowing it to serve as a router or access point. Just choose the mode for your network demands.

  •

    Router (Default)

    Instantly generate a private
    wireless network.

  •

    Access Point

    Create WiFi access for any
    existing wired network.

*Range Extender mode requires user to update the firmware to the latest version, which will be released soon.

WiFi Made Easy

  •

    App-Based Setup

    Installing Deco S4 is fast and easy. Just unpack the system, download the Deco app and follow its on-screen directions.

    Learn how to set up the Deco system >>
  •

    Easy Management

    Manage your WiFi at home or away in the Deco app, including seeing the connected devices, prioritizing your devices, setting up a guest network and more.

  •

    Voice Control

    Pair with Alexa to control Deco S4 with simple voice commands. Enjoy a convenient life.




Parental Controls

Simple, intuitive parental controls make it easy to
keep your children safe while they’re online.

  • Easily create a profile for each family member and set custom time limits and online time allowances.

  • Keep your family safe online with security settings that block websites based on age-appropriateness.

  • Set limits on how much time each person in your family can spend online.

  • Check out which sites your children visit and how much time they spend on each to ensure your children are safe while they’re having fun online.

  • Take a break from WiFi for dinner and family game nights. Just tap a button to suspend internet access for everyone in your home.







All Decos
Work Together

Deco S4 is compatible with every other Deco model to
form a Mesh network. Expand Mesh WiFi coverage
anytime by simply adding more Decos.

Deco M5
Deco M9 Plus
Deco S4
Deco M3W
Deco M9 Plus
Deco P7
Deco S4
Deco S4
Deco M3W
Deco M3W
POWER
AC adapter input 100-240V ~ 50/60Hz 0.4A
AC adapter output 12V ⎓ 1.5A
HARDWARE FEATURES
Processor Qualcomm CPU
Interface 2 Gigabit Ethernet Ports (WAN/LAN auto-sensing) per Deco unit
Button 1 Reset button on the underside
External Power Supply 12 V/1.5 A
Dimensions Φ3.6 in. x 6.4 in. (Φ90.7 mm x 162.3 mm)
Antenna Type 2 internal dual-band antennas per Deco unit
WIRELESS FEATURES
Wireless Standards IEEE 802.11 ac/n/a 5 GHz, IEEE 802.11 b/g/n 2.4 GHz
Frequency 2.4 GHz and 5 GHz
Signal Rate 300 Mbps on 2.4 GHz
867 Mbps on 5 GHz
Transmit Power FCC: <30 dBm
Wireless Security WPA-PSK/WPA2-PSK
Advanced Functions ● Router/ Access Point Mode
● Optional Ethernet Backhaul
● Guest network
● TP-Link Mesh Technology:
MU-MIMO
Auto Path Selection
Self-Healing
AP Steering
Band Steering
Beamforming
SOFTWARE FEATURES
Quality of Service WMM
IPv6 Support
WAN Type Dynamic IP/Static IP/PPPoE/L2TP/PPTP
Management Local Management, Remote Management
DHCP Server, Client
Port Forwarding Support
Access Control Blacklist
Firewall Security SPI Firewall
Protocols Supports IPv4 and IPv6
Advanced Features Parental Controls
Quality of Service
Advanced Functions Monthly Reports
Cloud FW Update
Expand WiFi by adding more Deco units
Guest Network 2.4 GHz guest network x 1
5 GHz guest network x 1
Beamforming Support
APP Easy setup via Deco App
OTHERS
Certification FCC, RoHS
Package Contents ● Deco S4 (3-pack):
3 Deco S4R units
1 RJ45 Ethernet Cable
3 power adapters
1 quick installation guide
Smartphone/Tablet Requirements iOS 9.0 or later, Android 4.4 or later
Environment Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing

Capability to connect 100 devices is based on testing using a mixed combination of devices. Maximum wireless transmission rates are the physical rates derived from IEEE Standard 802.11 specifications. Range, coverage, and maximum quantity of connected devices are based on test results under normal usage conditions. Actual wireless data throughput. wireless coverage, and quantity of connected devices are not guaranteed and will vary as a result of 1) environmental factors, including building materials, physical objects, and obstacles, 2) network conditions, including local interference, volume and density of traffic, product location, network complexity, and network overhead, and 3) client limitations, including rated performance, location, connection quality, and client condition.

Clients need to support 802.11k/v/r and may require additional set up. Performance may vary depending on the client device.
