TL-PA7020 KIT TL-PA7020 KIT

  • HomePlug AV2 standard compliant*
  • 2 gigabit ports create secure wired networks for desktops or IPTVs
  • Plug and play, no configuration required
  • Patented Power-Saving Mode automatically reduces power consumption by up to 85%**


AV1000

Ideal for Slick streaming and Smooth Downloads

Comes with advanced HomePlug AV2 technology, TL-PA7020 KIT provides users with high-speed data transfer rate, which is ideal for bandwidth intensive applications such as multiple HD/3D/4K video streaming, online gaming and large file transfers.*




2 Gigabit Ports
for Maximum Connectivity

With 2 gigabit Ethernet ports, TL-PA7020 KIT can simultaneously connect up to 2 wired-only devices. This makes the TL-PA7020 KIT the perfect home entertainment companion. Connect any 2 devices from smart TVs and games consoles to NAS boxes and computers to the Internet at the same time. Just plug the Ethernet cable into the powerline and away you go!

  • Game Console
  • 4K TV
  • Computer

Plug and Play,
No Configuration Required

Connect a powerline adapter to the router; plug another powerline adapter into a wall socket in another room, and connect it to your Internet enabled device via Ethernet - and you’re done!



Reduce Power Consumption by Up to 85%

TTL-PA7020 KIT, a new-generation of powerline adapter, with its practical design and sophisticated Power-Saving Mode, will automatically switch from its regular "Working" mode to "Power-Saving" mode reducing its energy consumption by up to 85%

  • Working mode
  • Power-Saving mode

*The terms “AV1000” and “1000Mbps” are derived from applicable specifications and refer to the theoretical maximum physical-layer data transfer rate. Those terms are used on this product solely to indicate its compatibility with other “AV1000” or “1000Mbps” powerline devices. Actual data speeds vary and may be limited by the product’s Ethernet port and other network conditions such as data traffic, electrical noise, and wiring issues. For better performance, powerline devices should be deployed on the same electrical circuit and rated for the same HomePlug standard. A minimum of two powerline devices are required to establish a powerline connection. If you are uncertain about your network conditions, you should consult an IT professional to assist in selecting a networking product.


**Actual power saved varies based on network conditions and environmental factors.





HARDWARE FEATURES
Plug Type US
Standards and Protocols HomePlug AV2, HomePlug AV, IEEE 1901,
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Interface 2 * Gigabit Ethernet Port
Button Pair Button
Power Consumption Maximum: 5.7W Typical: 4.7W Standby: 1.4W
LED Indicator PWR, PLC, ETH
Dimensions ( W x D x H ) 4.85*2.68*1.18 in. (123*68*30 mm)
Range 300 Meters over electrical circuit
SOFTWARE FEATURES
Modulation Technology OFDM (PLC)
Encryption Powerline Security: 128-bit AES
OTHERS
Certification FCC, RoHS, UL
Package Contents Powerline Ethernet Adapter
6.5 ft. (2 m) CAT.5e Ethernet cable (RJ45)
Quick Installation Guide
System Requirements Windows 2000/XP/2003/Vista, Windows 7/8/8.1/10, Mac, Linux
Environment Operating Temperature: 0°C~40°C (32°F ~104°F)
Storage Temperature: -40°C~70°C (-40°F ~158°F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
