AV1000 2-Port Gigabit Passthrough Powerline Starter Kit TL-PA7020P KIT
- HomePlug AV2 standard compliant, high-speed data transfer rates of up to 1000Mbps1, supports all your online needs
- 2 gigabit ports create secure wired networks for desktops or IPTVs
- Integrated power socket ensures no power outlet goes to waste
- Plug and play, no configuration required
- Patented Power-Saving Mode automatically reduces power consumption by up to 85%2
AV1000 Powerline Kit
Bring Your Home Network Into New Era
AV1000 2-Port Gigabit Passthrough
Powerline Starter Kit
Perfect for Bandwidth
Coming with advanced HomePlug AV2 technology, TL-PA7020P KIT provides users with
high-speed data transfer rates of up to 1000Mbps, which is ideal for bandwidth intensive
applications such as multiple HD/3D/4K video streaming, online gaming and large file transfers.
2 Gigabit Ports
for Maximum Connectivity
With 2 gigabit Ethernet ports, TL-PA7020P KIT can simultaneously connect up to 2
wired-only devices. This makes the TL-PA7020P KIT the perfect home entertainment
companion. Connect any 2 devices from smart TVs and games consoles to NAS boxes
and computers to the Internet at the same time. Just plug the Ethernet cable into the
powerline and away you go!
- Game Console
- 4K TV
Plug and Play,
No Configuration Required
Connect a powerline adapter to the router; plug another
powerline adapter into a wall socket in another room,
and connect it to your Internet enabled device via
Ethernet - and you’re done!
Extra Power Socket for Additional Devices
Where sockets are at a premium, the TL-PA7020P KIT with an integrated AC pass-through power socket, means the powerlines can be
used like a traditional electrical socket. Plug your smart TV or games consoles into the powerlines, as if it were a normal plug socket. No
socket needs to go to waste. The built-in noise filter helps to prevent electrical signal noise from affecting powerline performance.
*Power output of up to 16A is suitable for high-power
electrical appliances to be connected.
Power Save by Up to 85%
TL-PA7020P KIT, a new-generation of powerline adapter, with
its practical design and sophisticated Power-Saving Mode, will
automatically switch from its regular "Working" mode to
"Power-Saving" mode reducing its energy consumption by
up to 85%*
*Actual data will vary in different network conditions and environments.
- Working mode
- Power-Saving mode
|TL-PA8030P||TL-PA8010P||AV1300 Gigabit Passthrough Powerline Starter Kit TL-PA8010P KIT|
|HomePlug AV2 Standard||√||√|
|Ethernet Port||3 Gigabit Ports||1 Gigabit Port|
|Extra Power Socket||√||√|
|One Button Security||√||√|
|Power Saving Mode||85%||85%|
*1. The theoretical maximum channel data transfer rate is derived from HomePlug AV2 specifications. Actual data transfer rate will vary from network environment including: distance, network traffic, noise on electrical wires, building material and construction, quality of electrical installation and other adverse conditions.
*2. Actual data will vary because of the network conditions and environment factors.
*3. Compatible with all HomePlug AV and AV2 Standard Powerline adapters. This product may not be compatible with routers or gateways with firmware that has been altered, is based on open source programs, or are non-standard or outdated.
|Plug Type||EU, UK, FR|
|Interface||2 * Gigabit Ethernet Port, Power Socket|
Maximum: 6W (220V/50Hz)
Typical: 6W (220V/50Hz)
Standby: 0.5W (220V/50Hz)
|LED Indicator||PWR, PLC, ETH|
|Dimensions ( W x D x H )||5.2×2.8×1.7 in. (131×72×42 mm)|
|Range||300 Meters over electrical circuit|
|Power Output to Integrated Socket||13 A|
|Modulation Technology||OFDM (PLC)|
Powerline Ethernet Adapter
6.5 ft. (2 m) Ethernet cable (RJ45)
Quick Installation Guide
|System Requirements||Windows 2000/XP/2003/Vista, Windows 7/8/8.1, Mac, Linux|
Operating Temperature: 0°C~40°C (32°F ~104°F)
Storage Temperature: -40°C~70°C (-40°F ~158°F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
