Archer VR1210v

AC1200 Wireless Dual Band Gigabit VoIP VDSL/ADSL Modem Router

  • Super VDSL: The Latest Super VDSL (VDSL2 Profile 35b) tech delivers internet speeds of up to 350 Mbps
  • Speedy WiFi: Experience superb wireless connections with 867 Mbps (5 GHz) + 300 Mbps (2.4 GHz) dual band WiFi
  • Versatile Connectivity: Fully compatible with VDSL2/ADSL2+/ADSL2/ADSL standards, as well as fiber, cable, and 3G/4G internet services
  • Full Gigabit Ports: Take full advantage of broadband speeds up to 1 Gbps
  • Superior Range: Two fixed omnidirectional antennas with Beamforming technology provide stable wireless connections and optimal coverage
  • MU-MIMO Technology: Simultaneously transfers data to multiple devices to reduce congestion and boost the average throughput
  • Telephony: Make or receive phone calls over the internet simply by connecting the device to their existing telephone set.

AC1200 Wireless Dual Band Gigabit VoIP VDSL/ADSL Modem Router

Archer VR1210v

Super DSL - the Future of the Internet

The Archer VR1210v features Super VDSL (VDSL2 Profile 35b), the latest generation of DSL technology. Downstream is increased by up to 350 Mbps, 3.5× faster than its VDSL2 predecessor.

  • 24Mbps ADSL2+
  • 100Mbps VDSL2(Profile 17a)
  • 350Mbps Super VDSL(Profile 35b)

Lightning-Fast Wired Connections

Four Gigabit ports operate up to 10× faster than Fast Ethernet. Plug your gaming console, desktop, or IPTV in to 4K-ready speeds. The USB 3.0 port allows you to connect hard drives and transfer data up to 10× faster than USB 2.0. Quickly and easily share files, photos, music, and videos across your entire network.

USB 3.0 Port LAN Ports Files Photos Music Video Desktop Game Cosole IPTV

Better Coverage with Beamforming

Beamforming technology dramatically increases coverage by detecting wireless devices and concentrating signal strength towards them. Enjoy stronger, more stable connections—even as mobile devices move from room to room.

Beamforming

MU-MIMO: Efficient Wi-Fi for Every Device

MU-MIMO technology transmits data to multiple devices, simultaneously. No more bandwidth congestion of latency. All devices receive data more quickly as Wi-Fi is used more efficiently.

MU-MIMO Router Regular Router
HARDWARE FEATURES
Interface 4 10/100/1000Mbps RJ45 LAN Ports
1 10/100/1000Mbps RJ45 WAN Port
1 VDSL2 Port
2 FXS Ports
1 USB 3.0 Port
Button Power On/Off Button, WPS On/Off Button, Wireless On/Off Button, Reset Button
External Power Supply 12V/1.5A
Wireless Standards IEEE 802.11ac/n/a 5GHz, IEEE 802.11b/g/n 2.4GHz
IEEE Standards IEEE 802.3, IEEE 802.3u, 802.3ab
VDSL2 Standards ITU G.993.2, Up to 35b profile ITU-T G.993.5 (G.vector) ITU-T G.998.4 (G.INP)
ADSL Standards Full-rate ANSI T1.413 Issue 2 ITU-T G.992.1 (G.DMT) ITU-T G.992.2 (G.Lite) ITU-T G.994.1 (G.hs) ITU-T G.995.1
ADSL2 Standards ITU-T G.992.3 (G.DMT.bis) ITU-T G.992.4 (G.lite.bis)
ADSL2+ Standards ITU-T G.992.5
Dimensions ( W x D x H ) 8.4 × 5.7 ×3.2 in (214.0 × 144.5 × 80.0 mm)
Antenna Internal Antennas
Antenna Type Internal antennas
Antenna Gain 3 x 2dBi for 2.4GHz and 4 x 2dBi for 5GHz
WIRELESS FEATURES
Frequency 2.4GHz and 5GHz (Supports DFS)
Signal Rate 867Mbps at 5GHz, 300Mbps at 2.4GHz
Transmit Power <20dBm (2.4GHz), <23dBm (5GHz Band1 & Band2), <30dBm (5GHz Band3)
Wireless Functions Enable/Disable Wireless Radio, WMM, Wireless Statistics
Wireless Security 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA-PSK2 encryptions
DHCP Server, Client, DHCP Client List, Address Reservation, DHCP Relay
Wireless Schedule Support 2.4GHz and 5GHz Wireless Schedule
SOFTWARE FEATURES
Quality of Service ATM QoS, QoS
Security NAT Firewall, SPI Firewall, Access Control, Service Filtering, Denial of Service (DoS), SYN Flooding, Ping of Death, IP and MAC Address Binding
Management Web Based Configuration (HTTP / HTTPS ), Remote management, Command Line Interface, SSL for TR-069, SNMP v1/2c, Firmware Up grade, Diagnostic Tools, Web Based Firmware Upgrade
Port Forwarding Virtual Server, Port Triggering, DMZ, ALG, UPnP
Dynamic DNS DynDns, NO-IP
VPN OpenVPN, PPTP VPN, IPSec VPN
Protocols Support IPv4 and IPv6
ATM/PPP Protocols ATM Forum UNI3.1/4.0, PPP over ATM (RFC 2364), PPP over Ethernet (RFC2516), IPoA (RFC1577/2225), MER\IPoE (RFC 1483 Routed), Bridge (RFC1483 Bridge), PVC – Up to 8 PVCs
Advanced Functions Parental Controls, Network Address Translation(NAT), Port Mapping (Grouping), Static Routing, RIP v1/v2 (optional), DNS Relay, DD NS, IGMP V1/V2/V3
USB Sharing Support Samba (Storage) / FTP Server / Media Server
Guest Network 2.4GHz guest network, 5GHz guest network
IPSec VPN Support up to 10 IPSec VPN tunnels
OTHERS
Certification CE
System Requirements Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1, 10, MAC OS, NetWare, UNIX or Linux Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0 , or other Java-enabled browser Cable or DSL Modem
Environment Operating Temperature: 0℃–40℃(32℉–104℉)
Storage Temperature: -40℃–70℃(-40℉–158℉)
Operating Humidity: 10%–90% non-condensing
Storage Humidity: 5%~90% non-condensing

*Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specifications. Actual wireless data throughput and wireless coverage, and quantity of connected devices are not guaranteed and will vary as a result of network conditions, client limitations, and environmental factors, including building materials, obstacles, volume and density of traffic, and client location.
