Meet the 6th Generation of Wi-Fi
The Wi-Fi 6, is designed to improve overall spectral efficiency, especially in dense usage scenarios.
The Purpose of 802.11ax
In 2019, there is estimated 14.96 billion devices wolrdwide connected via WLAN, and it is projected that in 2021, the number will grow to 22.2 billion.* Thus, future Wi-Fi networks need to be capable of managing increased data traffic and more Wi-Fi signals. IEEE 802.11ax (Wi-Fi 6), a revolutionary high-efficiency Wi-Fi standard, rises to the challenge. It holds great promise to provide faster and more stable network experience for the next decade.*Data from report of Statista
Up to 9.6 Gbps Speed
1024-QAM and increased OFDM symbol time combine to offer astonishing Wi-Fi Speed and an extended range compared to previous generations of Wi-Fi. Feel free to enjoy smooth 4K streaming and immersive VR gameplay in every room or even your back yard with a faster, more robust 802.11ax connection.
4x Larger Capacity
This revolutionary OFDMA is introduced into 11ax for optimized frequency allocation, cooperating with revised MU-MIMO for both up-link and down-link and BSS color for smarter transmission; boosting your router’s ability to serve more clients, even while under overlapped signals.
|PHY||Number of data
|Coding rate||Bits/symbol||Time per OFDM
symbol (0.4μs GI)
|802.11ac||234 (80 MHz)||× 5/6||× log2(256)||÷ 3.6 µs||=||433.3 Mbps||1.74 Gbps||NA|
|802.11ax||1960 (160 MHz)||× 5/6||× log2(1024)||÷ 13.6 µs||=||1.2 Gbps||4.8 Gbps||9.6 Gbps|
Higher Level Modulation
25% faster than 256-QAM
With 1024-QAM, each symbol carries 10 bits rather than 8 bits, improving raw speeds by 25% compared to 802.11ac 256-QAM. Fully enjoy bandwidth extensive activities like immersive VR through a wireless headset.
|Number of Data Subcarriers||234||980|
|Symbol Duration(μs)||3.6 (3.2 symbol + 0.4 GI)||13.6 (12.8 symbol + 0.8 GI)|
|Valid Data Subcarriers Rate||65||72.05882|
4× Longer OFDM Symbol
1.1× More Speed and Greater Stability
OFDM divides the high data rate transmission into multiple low data rate sub-carriers, and low data rate means more stability and wider coverage. In 802.11ax, a 4× longer OFDM symbol and a longer GI were applied to generate 4× sub-carriers. Coverage grows, as does the proportion of data sub-carriers, helping AX Wi-Fi to be 11% faster.
160MHz Channel Width on a Single Stream
Broader the Road, Double the Load
With channel width reaching up to 160 MHz, 802.11ax can deliver wireless speeds beyond what you can imagine.
Fully Utilized Bandwidth Eradicates Latency
Wireless efficiency drops as the density of client devices increases and large number of short packets are transmitted, causing more contention and collision. 802.11ax uses OFDMA technology for more efficient access. OFDMA divides the spectrum into Resource Units and allocates them to multiple different users, if necessary, allowing multiple users with varying bandwidth needs to be served simultaneously. Like a delivery truck carrying packages for different receivers on a single trip—which is clearly more efficient—in both up-link and down-link directions.
WaitingClient 2WaitingData Transmitted
802.11ac | without OFDMA
Client 1Client 2Client 3Data Transmitted
802.11ax | OFDMA
8 × 8 MU-MIMO
Downlink, Uplink, All Aboard MU-MIMO
While OFDMA is introduced for making one wave support multiple clients, MU-MIMO is dedicated to achieve the same goal of improving efficiency by taking advantage of space to create more spatial streams. 802.11ax multiplies the performance of 802.11ac by generating up to 8 streams on single direction and directing them to multiple spatially diverse clients, simultaneously. By adding a new trigger control frame, 802.11ax now supports up-link multi-user MIMO transmissions.
Minimizing Wi-Fi Conflicts with Your Neighbors
Interference from your neighbors' wireless networks can cause issues with your wireless signal. BSS (Base Service Station) Color, as an identifier, can mark each frame and tell Routers/APs/Clients which frames are coming from neighboring networks and ignore them, as long as the existing frames are below a threshold of weakness, avoiding unnecessary slowdown and minimize Wi-Fi interference from the neighborhood to the most extent.
Target Wake Time
Arrange Client Connections and Reduce Power Consumption
Target Wake Time (TWT) allows devices to negotiate when and how often they will wake up to send or receive data, increasing device sleep time and substantially improving battery life for mobile and IoT devices.
