NE225-Outdoor
Coming Soon5G Outdoor Gateway
-
Unrivaled Speed with 5G: Download speeds reach up to 7.01 Gbps.
-
LTE-Advanced Cat 19: Download speeds up to 1.6 Gbps.
-
Performance-Driven for Outdoor Environments: 1× 2.5GE PoE Port.
-
IP66 Weatherproof: Withstands environments with rain and dust.
-
Plug and Play: No configuration needed. Compatible with SIM cards in 100+ countries.
-
Remote Management: TR-069 and TR-369 protocols are supported.
Break Down
Barriers with 5G
5G Outdoor Router
NE225-Outdoor
Unrivaled Speed, Feel No Lag
5G 4G+ 7.01 Gbps 1.6 Gbps High-GainAntennas Plug & Play IP66 ±6kVLightning
Protection ±15kVESD
Protection 2.5G
PoE Port PoE-Powered
Support Simple and Efficient
Deployment TR-069/TR-369
Remote Management
Unrivaled Speed with 5G,
Revolutionary Experience
With massive MIMO, optimized OFDM, and more, 5G delivers blazing-fast downloads up to 7.01 Gbps and ultra-responsive connections with just 1ms latency, perfect for the next generation of mobile devices.
- Higher
Speed - Lower
Latency - Larger
Capacity
More Coverage.
Stronger Signals.
Higher Reliability. Unrivaled Speed with 5G,
Revolutionary Experience
NE225-Outdoor features up to 10dBi antennas, combining optimized antenna design and anti-interference technology for stronger, more reliable connections and maximized performance. With massive MIMO, optimized OFDM, and more, 5G delivers blazing-fast downloads up to 7.01 Gbps and ultra-responsive connections with just 1ms latency—perfect for the next generation of mobile devices.
Station NE225-Outdoor 5G Cellular
Network Wired
Connection Router Up to
10dBi
Install Your Router Anywhere
NE225-Outdoor fits multiple application scenarios with four types of installation methods*. A single cable for power and data removes most location limits.
PoE Port
Extend High-Speed Internet Access Indoors
Unlike indoor 5G routers, NE225-Outdoor receives outside 5G access throughout your home or office. Wired to an indoor router, it delivers fast, stable 5G access throughout your home or office.
Network Plug & Play Flexible Installation Pole Mounting Wall Mounting Window Sill Window Mounting Data+Power PoE Injector Power Data Gateway
Quick Onboarding with the Aginet App Quick Onboarding with the Aginet App
Easily find the best spot for a 5G Outdoor Router. Just download the app, connect via QR code or Bluetooth, and install the router in a suitable place. Easily find the best spot for a 5G Outdoor Router. Just download the app, connect via QR code or Bluetooth, and install the router in a suitable place.
Compact and Durable for the Outdoors
Durable outdoor design with a compact, lightweight, and weatherproof shell. Built-in lightning and ESD protection ensure reliable performance in any weather.
Compact and Durable for the Outdoors
Durable outdoor design with a compact, lightweight, and weatherproof shell. Built-in lightning and ESD protection ensure reliable performance in any weather.
- IP66 Weatherproof‡
- ±6kV Lightning Protection△
±15kV ESD Protection△ - -30℃–50℃
- IP66 Weatherproof‡
- ±6kV Lightning Protection△
±15kV ESD Protection△ - -30℃–50℃
6: Completely dust-tight. No ingress of dust.
7: Protection against full immersion in water up to 1 meter deep for half an hour.
-
±6kV Lightning Protection and
±15kV ESD Protection -
No Ingress of Dust
-
Waterproof Enclosure
Appearance
Terminal Ethernet
LAN Port SIM Card Signal Strength Network Type/Bluetooth Power 1.4 in 7.2 in 4.3 in
| CPU | 2.0 GHz CPU |
|---|---|
| Interface | 1× 2.5GE PoE/LAN Port + 1 Nano SIM |
| Button | 1 RESET button |
| External Power Supply | • 802.3at PoE• 48V Passive PoE (PoE Adapter Included) |
| Dimensions ( W x D x H ) | 7.2 x 4.3 x 1.4 in (183 x 110 x 36mm) |
| Antenna | Internal 5G NR/LTE Antennas |
| Protection | IP66 |
| Mounting | Pole/Wall/Window Mounting |
| Bluetooth version | v5.4 Supported |
| Signal Rate | 5G SA : 7.01 Gbps(downstream) / 1.25 Gbps(upstream) 5G NSA: 5.67 Gbps(downstream) / 830 Mbps(upstream) LTE: 1.6 Gbps(downstream) / 211 Mbps(upstream) WCDMA: 42 Mbps(downstream) / 11.5 Mbps(upstream) |
|---|---|
| Network Type | 5G: n1/n3/n5/n7/n8/n20/n28/n38/n40/n41/n75/n76/n77/n784G: B1/B3/B5/B7/B8/B20/B28/B32/B38/B40/B41/B42/B433G: B1/B5/B8 |
| Advanced Features | Address Reservation, Port Forwarding, Cloud Upgrade, IPv6, NAT Forwarding, Firewall, Network Diagnostic, CWMP, Traffic Statistic, IPSEC VPN, PPTP VPN, OpenVPN |
|---|---|
| Protocols | IPv6 Compatible |
| WAN Type | Dynamic IP |
| Management Features | Local management: WebGUI management, Aginet App management Remote management: TR-069, TR-098, TR-181, TR-111, TR-143 |
| Certification | CE |
|---|---|
| Package Content | 1× NE225-Outdoor1× PoE Adapter1× RJ45 Ethernet Cable1× Quick Installation GuidePole/Wall/Window Mounting Kits |
| System Requirements | Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1,10, MAC OS, NetWare, UNIX or Linux Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0 browers or higher. |
| Environment | Operating Temperature: -30°C~50°C (-22°F ~122°F)Storage Temperature: -30°C~70°C (-22°F ~158°F)Operating Humidity: 5%~95% non-condensingStorage Humidity: 5%~90% non-condensing |
