AV2000 Gigabit Powerline ac Wi-Fi Kit TL-WPA9610 KIT
- AV2000 Powerline Speed – meets the demand for bandwidth-intensive activities with the latest, fastest powerline transfer rates
- AC1200 Dual-Band Wi-Fi – delivers combined speeds of up to 1200 Mbps, delivering a fast and seamless wireless network to all your smartphones, tablets and computers
- Wi-Fi Auto-Sync – instantly configures additional extenders to your powerline network by uniformly syncing settings such as SSID, password, Wi-Fi Schedule and LED Schedule across all network devices
- Plug, Pair and Play – allows setup of your powerline network in minutes, so you can enjoy fast, seamless wired and wireless connections right away
- Easy Management – gives you easy control of your network through a powerful web interface, the user-friendly tpPLC utility and the intuitive tpPLC mobile app
Break the Powerline Speed Limit
AV2000 Gigabit Powerline ac Wi-Fi Kit
Faster than faster over the Powerline
The latest HomePlug AV2 technology delivers speeds of up to 2000Mbps over Powerline, preventing lost speed during transfers. Through the Gigabit Ethernet port, your experience is just like a direct link to your router.
Stable Connections Thanks to 2×2 MIMO
2×2 MIMO is like adding extra lanes to a highway. This doubles transfer speeds, as well as avoids interference from other appliances, providing speed with stability.learn more about 2X2 MIMO
2×2 MIMO with Beamforming
More Stable Connections
2X2 MIMO is like adding extra lanes to a highway. It establishes multiple simultaneous connection for you to enjoy higher speeds and greater stability.
- SISO - Single-input Single-output
- MIMO - Multi-input Multi-output
2X2 MIMO with Beamforming Technology also offers the benefit of improved coverage throughout the home, particularly for previously hard to reach outlets.
- Long Distance
- Long Distance
High Speed Dual Band Wi-Fi – Up to 1.2Gbps
The TL-WPA9610 provides high-speed dual band Wi-Fi
of up to 1.2Gbps for your need. Use the 300Mbps
2.4GHz band for surfing and emailing, or switch to the
867Mbps 5GHz band for 4K streaming and lag-free
gaming on multiple devices at the same time.
Plug, Pair, and Play
Ditch the complicated setup process for good. With TP-Link
powerline adapters, all it takes is three steps to get online.
First, connect your TL-PA9020 to the router.
Then, plug in the TL-WPA9610 wherever you need extra coverage.
Finally, press the “Pair” button on each adapter.
Wi-Fi Auto-Sync now combines two technologies for a simple, smart network. Pressing the Wi-Fi Clone button instantly copies your network name and password from your router for easy setup. Wi-Fi Move automatically applies any settings changes across the network. Together, manage your Wi-Fi network easier than ever.
- User Name :
- Password :
- User Name :
- Password :
Pretty and Practical
A streamlined minimalist design fits perfectly in any home. Rounded corners ensure safety for everyone in the family. A complete 360° venthole prevents overheating for cool, unhindered performance.
*1. Compatible with all HomePlug AV and AV2 Standard Powerline adapters. This product may not be compatible with routers or gateways with firmware that has been altered, is based on open source programs, or are non-standard or outdated.
*2. Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specifications. Actual wireless data throughput and wireless coverage are not guaranteed and will vary as a result of 1) environmental factors, including building materials, physical objects, and obstacles, 2) network conditions, including local interference, volume and density of traffic, product location, network complexity, and network overhead, and 3) client limitations, including rated performance, location, connection, quality, and client condition.
*3. Maximum Powerline signal rates are the physical rates derived from HomeplugAV/AV2 specifications. Actual Powerline data throughput and Powerline range are not guaranteed and will vary as a result of network conditions and environmental factors, including electrical interference, volume of traffic and network overhead, AFCI circuit breaker, and Powerline being located in a separate circuit.
|Standards and Protocols||HomePlug AV2, IEEE 1901,IEEE 802.3,IEEE 802.3u,IEEE 802.11b/g/n 2.4GHz, IEEE 802.11a/ac 5GHz|
|Interface||TL-WPA9610：1*Gigabit Ethernet PortTL-PA9020：2*Gigabit Ethernet Port|
|Button||Pair, Reset, LED On/Off, Wi-Fi Clone|
|Power Consumption||TL-WPA9610：Maximum: 14 W Typical:10WStandby: 7 W TL-PA9020：Maximum: 5.8 W Typical:5.6WStandby: <0.6 W|
|LED Indicator||Power, Powerline, Ethernet, 2.4G Wi-Fi, 5G Wi-Fi|
|Dimensions ( W x D x H )||TL-WPA9610：5.5 x 3.1 x 1.9 in. (140.5×77.5×48 mm)TL-PA9020：4.85 x 2.68 x 1.18 in. (123×68×30 mm)|
|Range||300 meters in house/1000 feet over existing electrical wiring|
|Compatibility||Compatible with all AV2000, AV1200, AV1000, AV600, AV500 &AV200 powerline adapters|
|Transmission Speeds||Powerline: up to 2000 MbpsWi-Fi：up to 1200 MbpsEthernet: 10/100/1000 Mbps|
|Quality of Service||ToSSupports up to 4-level type QoSSupport up to 8-level VLAN priority field|
|Security||128-bit AES Encryption|
|Package Contents||AV2000 Gigabit Powerline ac Wi-Fi Kit: TL-WPA9610 & TL-PA90202-meter CAT.5e Ethernet Cable * 2Quick Installation Guide|
|System Requirements||Windows 10/8.1/8/7/Vista/XP, Mac OS, Linux1|
|Environment||Operating Temperature: 0°C ~ 40°C (32°F ~ 104°F)Storage Temperature: -40°F ~ 158°F (-40°C ~ 70°C )Operating Humidity: 10% ~ 90% non-condensingStorage Humidity: 5% ~ 90% non-condensing|
