N300 Wireless Gigabit VDSL/ADSL Modem Router
- Providing broadband speeds up to 100Mbps over VDSL2 and backward compatible with ADSL
- Broadcom chipset maximizes modem compatibility
- Gigabit Ethernet ports ensure ultrafast data transfer speeds
- Tether APP provides easy network management at your fingertips
Upgrade Your Home Network with Gigabit Wired and Stronger Wireless Coverage
N300 Wireless Gigabit VDSL/ADSL Modem Router
More Than a Modem Router
- • VDSL2 technology delivers VDSL broadband speeds of up to 100Mbps. The integrated DSL port supports all standard DSL connections*. Combined with 300Mbps Wi-Fi speed, the TD-W9977 is a fast, stable modem router.
- • As a backup, the EWAN port allows the TD-W9977 to work as a router and accept connections from Cable or Fiber modem via Ethernet cable.
- * TD-W9977 is compatible with VDSL2, ADSL2+, ADSL2, and ADSL.
- Upstream Rate
- Downstream Rate
1. Modem Router Mode
2. Router Mode
A Perfect Match for Your ISP
We all know the biggest challenge when looking for the right DSL modem: will it work with your ISP? That’s why the TD-W9977 comes with a chipset from Broadcom, the world’s No. 1 in DSL products, providing integrated solutions for more than 100 Internet Service Providers around the globe. This maximizes modem compatibility, saving you time and energy to find the perfect modem.
Outstanding Network Performance
Wired Network Improvement
Gigabit Ethernet ports operates 10x the speed
of standard ports, giving you faster, stronger
connections for your PC, game console and IPTV.
Wireless Network Improvement
Three 5dBi high-gain antennas provides wider Wi-Fi coverage across your home.
Your Network, Secure as Always
A series of firewall security functions defends your network from any unwanted access or harm. Parental Controls and Guest Network help you manage secure access to all your friends and family. Finally, 6kV Lighting Protection shields the TD-W9977 from electrical damage from thunderstorms.
Easy Management with Tether
TP-Link‘s free Tether app helps you manage your TD-W9977 from any Android or iOS device. This feature-rich phone app gives you access to hassle-free installation and every advanced network management feature, all at your fingertips.
WPS Button helps you easily expand your network connect to other Wi-Fi devices.
Supports up to 10 IPSec VPN tunnels.
Supports Bridge and Tag VLAN for smooth IPTV application.
Supports IPv6, the foundation of the next generation of the internet to enable a range of new services.
|Interface||4 10/100/1000Mbps RJ45 Ports1 RJ11 Port|
|Button||1 Power On/Off Button1 WPS Button1 Wi-Fi On/Off Switch1 RESET Button|
|External Power Supply||12VDC/1A|
|IEEE Standards||IEEE 802.3IEEE 802.3uIEEE 802.3ab|
|VDSL2 Standards||ITU G.993.2, Up to 17a profile(POTS)ITU-T G.993.5(G.vector)ITU-T G.998.4(G.INP)|
|ADSL Standards||Full-rate ANSI T1.413 Issue2ITU-T G.992.1(G.DMT)ITU-T G.992.2(G.Lite)ITU-T G.994.1 (G.hs)ITU-T G.995.1|
|ADSL2 Standards||ITU-T G.992.3(G.DMT.bis)ITU-T G.992.4(G.lite.bis)|
|ADSL2+ Standards||ITU-T G.992.5|
|Dimensions ( W x D x H )||243.5×167.5×32.7mm|
|Antenna Type||3 fixed external antennas|
|Wireless Standards||IEEE 802.11b/g/n 2.4GHz|
|Transmit Power||2.4GHz <20dBm(EIRP)|
|Wireless Security||64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA-PSK2 encryptions, Wireless MAC Filtering|
|Wireless Schedule||Support 2.4GHz Wireless Schedule|
|Quality of Service||Bandwidth Control|
|Security||NAT Firewall, Access Control, IP and MAC Address Binding|
|IPv6||DHCPv6 Server, DHCPv6 Client, ICMPv6, 6to4, 6RD, DSLITE|
|Operating Modes||VDSL/ADSL Modem Router, Wireless Router|
|Management||Web Based Configuration(HTTP), Remote management, Command Line Interface, SSL for TR-069, SNMP v1/2, Web Based Firmware Upgrade, Diagnostic Tools|
|Port Forwarding||Virtual Server, Port Triggering, DMZ, ALG, UPnP|
|VPN Pass-Through||PPTP, L2TP, IPSec Passthrough|
|ATM/PPP Protocols||ATM Forum UNI3.1/4.0, PPP over ATM(RFC 2364), PPP over Ethernet(RFC2516), IPoA(RFC1577/2225), MER/IPoE(RFC1483 Routed), Bridge (RFC 1483 Bridge), PVC-Up to 8 PVCs|
|Advanced Features||Parental Control, Network Address Translation(NAT), Port Mapping, Static Routing, RIP v1/v2(optional), DNS Relay|
|IPSec VPN||Support up to 10 IPSec VPN tunnels|
|Certification||CE, RoHS, RCM|
|Package Contents||N300 Wireless Gigabit VDSL/ADSL Modem Router TD-W9977External SplitterRJ11 DSL CableRJ45 Ethernet CablePower AdapterQuick Installation Guide|
|System Requirements||Microsoft Windows XP/7/8/8.1/10, MAC OS, NetWare, UNIX or LinuxInternet Explorer, Firefox, Chrome, Safari or other Java-enabled browserSubscription with an Internet Service Provider|
|Environment||Operating Temperature: 0℃~40℃(32℉~104℉)Operating Temperature: -400℃~70℃(-40℉~158℉)Operating Humidity: 10%~90% non-condesnsingStorage Humidity: 5%~90% non-condensing|
