RE765X
AX3000 Wi-Fi 6 Range Extender with AC Passthrough
- Up to 3.0 Gbps Dual Band Wi-Fi: Separates 5 GHz (2402 Mbps) and 2.4 GHz (574 Mbps) WiFi bands for faster speeds and greater capacity with the WiFi 6 technology.†
- Flexible Placement & Extra Plug: The RE765X’s compact, wall-mounted design offers easy setup and flexible relocation. Just plug it in anywhere, no reconfiguration needed. Its built-in power socket keeps your outlet available.
- Smart Roaming: Walk from room to room and stay connected with the fastest possible speeds.§
- EasyMesh-Compatible: Flexibly creates a Mesh network by connecting to an EasyMesh-compatible router for seamless whole-home coverage.◇
- AP Mode: Create a new WiFi access point through the Gigabit Ethernet port to enhance your wired network with WiFi capability.
- Adaptive Path Selection: Automatically choosing the fastest connection path to the router.
- Easy Setup: Plug in and then easily set up via a press of the WPS button or via the Tether App.
- Ultimate Compatibility: Extends the range of any Wi-Fi router or wireless access point.*
Boost your Wi-Fi
Extend Coverage, Free Your Outlets!
AX3000 Wi-Fi 6 Range Extender with AC Passthrough
RE765X
Smart Plug Integrated
160MHz Band Width
Streaming Network for Multi-Devices
EasyMesh
1 Gigabit
Ethernet Port
AX3000
Blazing-Fast Wi-Fi
5 GHz
2402 Mbps
2.4 GHz
574 Mbps
Works with any Wi-Fi Router
MU-MIMO
Effortlessly Expand Your Wi-Fi Coverage*
Say goodbye to Wi-Fi dead zones in your home. The RE765X Range Extender wirelessly connects to your router, boosting and extending its signal to reach areas beyond its usual range. Experience dependable, uninterrupted Wi-Fi coverage throughout your home or office, with minimized signal interference for a smoother connection.
Flexible Placement & Extra Plug
The RE765X’s compact, wall-mounted design offers easy setup and flexible relocation. Just plug it in anywhere, no reconfiguration needed. Its built-in power socket keeps your outlet available.
Smart Energy Monitoring
Take control of your power usage! Track energy consumption and get bill estimates to save more on electricity.
Real-Time: 100W
Past 7 Days: 0.2KWh
Power up or down from anywhere. With the Tether app, you’re always in control of your devices.
Set a time table for the plug to auto turn on and off every day.
8:00PMSet a time period for the plug to auto turn off every time.
Turn off in 1 hour laterUnleash the Power of Wi-Fi 6
Faster, Stronger, Smarter
Step into the future with blazing-fast Wi-Fi 6. Enjoy up to 25% faster speeds, smoother streaming, and seamless connections across all your devices. Thanks to advanced 1024-QAM technology, every corner of your home is covered with high-speed, stable Wi-Fi.
Wi-Fi 6 1024-QAM
25% faster
Wi-Fi 5 256-QAM
4K/8K Streaming
Video Conferencing
Online Gaming
VR/AR
Higher Efficiency, Lower Latency
Double Channel Speed with HE160
Supports 2x2 160MHz on the 5G band, enjoys wider bandwidth and faster speed than the traditional 80MHz.
Coverage Wherever You Need It
Enjoy seamless 4K streaming and gaming in every room with the powerful RE765X’s four high-performance amplifiers. Whether you’re sharing space with friends or settling into your forever home, RE765X delivers strong, reliable signals to even the hardest-to-reach corners.
OFDMA
More efficient data.
WiFi 6 OFDMA
Data Transmitted
WiFi 5 OFDMA
Data Transmitted
Beamforming
Strong, targeted WiFi.
Beamforming
None
Orthogonal Frequency Division Multiple Access helps integrate the data of different end devices for higher efficiency.
Find the direction of your phone or laptop, and accelerate your signal strength.
Adaptive Path Selection
Keeps your network running at top speed by automatically choosing the fastest connection path to the router.
Without Adaptive Path Selection
Wide. Wider. Widest.
Keep your internet focused on a single room or blanket an entire floor with WiFi by picking between 3 strength levels on the Tether app.
EasyMesh — Flexibly Create Whole Home Mesh WiFi
RE765X is EasyMesh-compatible. If you have any dead zones at home, just add another EasyMesh router/range extender to further form your whole home multi-gigabit mesh WiFi. No more searching for a stable connection.
-
One WiFi Name
No more switching WiFi network names
-
Smart Roaming
Uninterrupted streaming when moving around your home
-
WiFi Dead Zone Killer
Eliminate weak signal areas with WiFi coverage for the whole house
-
Unified Management
Manage your whole home WiFi from the central node via the Tether app/Web UI
-
EasyMesh Devices (Router+Range Extender)
-
Traditional Router with Extender WiFi
Built-In Access Point Mode
The RE765X is more than just a range extender. With Access Point Mode, plug in an Ethernet cable to instantly transform your wired network into a high-speed, dual band wireless hub, reaching speeds up to 1,000 Mbps. Perfect for seamless connectivity in every corner of your space
Control at Your Fingertips
Set up and manage your WiFi, including TP-Link routers and range extenders, from your Android or iOS phone with the TP-Link Tether app.
| HARDWARE FEATURES | |
|---|---|
| Interface | 1 Gigabit Ethernet Port |
| Button | • WPS Button• Reset Button |
| Input Power | 100-240V~50/60Hz |
| Max. Power Consumption | 15.2W |
| Antenna | 2 External Antennas |
| WIRELESS FEATURES | |
|---|---|
| Wireless Standards | • IEEE 802.11a/n/ac/ax 5GHz• IEEE 802.11b/g/n/ax 2.4GHz |
| Frequency | 2.4GHz and 5GHz |
| Signal Rate | • 574 Mbps at 2.4GHz• 2402 Mbps at 5GHz |
| Working Modes | Range Extender / Access Point |
| Reception Sensitivity | 5GHz: 11a 6Mbps:-97dBm11a 54Mbps:-78dBm11ax HE20 MCS0: -97dBm 11ax HE20 MCS11: -66dBm11ax HE40 MCS0: -94dBm 11ax HE40 MCS11: -62dBm11ax HE80 MCS0: -92dBm 11ax HE80 MCS11: -61.5dBm 11ax HE160 MCS11: -59dBm 2.4GHz: 11g 6Mbps:-96dBm11g 54Mbps:-78dBm11ax HE20 MCS0: -95dBm 11ax HE20 MCS11: -66dBm11ax HE40 MCS0: -93.5dBm 11ax HE40 MCS11: -62dBm |
| Wireless Functions | • Enable/Disable Wireless Radio• DFS (the latest firmware and hardware version is required)• Access Control• LED Control• Power Schedule• Wi-Fi Coverage Adjustment |
| Wireless Security | • WEP• WPA• WPA2• WPA3 |
| Transmission Power | • 2.4 GHz ≤ 16 dBm• 5 GHz ≤ 21 dBm |
| Mesh Technology | EasyMesh-Compatible |
| OTHERS | |
|---|---|
| Certification | RoHS |
| Package Content | • Wi-Fi Range Extender RE715X • Quick Installation Guide |
| System Requirements | Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1, 10, MAC OS, NetWare, UNIX or Linux Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser |
| Environment | • Operating Temperature: 0℃~40℃ (32℉ ~104℉)• Storage Temperature: -40℃~70℃ (-40℉ ~158℉)• Operating Humidity: 10%~90% non-condensing• Storage Humidity: 5%~90% non-condensing |
