Tapo DL130
Coming SoonPalm Access Smart Lock | Wi-Fi Deadbolt with Fingerprint | TP-Link
- Just hold up your hand to get in: Palm vein recognition reads your palm for fast, touch-free entry. No fingers to press, no code to remember.
- 7 ways to unlock, so there's always a way in: Palm, fingerprint, app, keypad PIN, Bluetooth, voice assistant, or a physical key.
- Your palm and fingerprint stay on the lock, not online: They're encrypted and stored on the device itself, never uploaded to the cloud.
- Shuts down after too many failed tries: If someone enters the wrong code, palm, or fingerprint too many times, the lock disables itself and sends you a notification.
- Locks itself once the door is shut: A built-in sensor detects when the door is closed, then locks automatically, so there's no need to double-check.
- Hear when someone's at the door: A built-in doorbell lets visitors ring so you know they've arrived.
- Lock and check it from your phone, anywhere: Use the Tapo app to lock, unlock, and see if the door's secured. A log shows every time it's opened or locked.
- Give guests their own way in: Create one-time or scheduled codes for family and guests, and change or remove them anytime in the app.
- Keeps working while it charges: When the main battery runs low, recharge it without taking the lock offline. The built-in backup keeps it running so you're not locked out.
- Works with the voice assistant you already have: Compatible with Amazon Alexa, Google Assistant, and Samsung SmartThings.
- Install it yourself in about 15 minutes: No need to call for help. Includes all the necessary accessories, detailed instructions, and step-by-step video guides. Just bring your own screwdriver.
- Handles rain, dust, heat, and cold: IP65 weather resistance and BHMA Grade 2 certification for year-round durability.
Secure Access.
Right in Your Palm.
Palm Access Smart Lock
7 Ways to unlock
Palm Recognition
Fingerprint
Passcode
Wi-Fi Access
Voice Control
Bluetooth Access
Physical Key
Timed Auto Lock
Once Closed
Door Left Open
Alarm & Alert
Real-Time
Notifications
See Who Comes
and Goes
Control from
Anywhere
Manage Users
and Guests
Check Door
& Lock Status
Certified
& Reliable
Professional
BHMA Grade 2
Weatherproof
Resistance
DuoBiometrics™
Access
Palm
Fingerprint
Dual-Battery
Design
Rechargeable
Battery
Built-In
Backup
Battery
Unmatched Security
Your Palm. Your Key.
Impossible to Copy.
The Tapo Palm Access Smart Lock reads the unique vein pattern inside your hand, something no photo or 3D model can fake. Even identical twins have different vein patterns, making your palm a key that only you can use.
Contactless Access for Everyone, Everywhere
Made for Every Hand
From aging hands to kids' hands, even when wet, dirty, or sweaty, the lock recognizes any palm.
Elderly
Child
Dirty Hand
Sweaty Hand
Access, Anytime
From bright sunlight to night, advanced sensors read your palm clearly from any angle.
Your Privacy, Locked In.
Stored Safely Inside the Lock — never
sent online or left vulnerable to hackers.
Encrypted to keep your information
private with AES 128 encryption
Extra protection with two-step
authentication
Always Powered. Never Locked Out.
Rechargeable
Battery
Built-in
Backup Battery
Built-in backup power keeps the lock
running even if the main battery runs low
Monitor battery levels
anytime in the app
Rechargeable design
means no
disposable
batteries are ever
needed
*'Always powered. Never locked out.' describes intended operation with regular battery charging and maintenance. Actual performance may vary if batteries are not maintained or charged as directed.
The dual-battery system is engineered for reliable, uninterrupted access. When the main battery is removed for charging, a built-in backup cell keeps the lock powered. Once reinstalled, the main battery can even recharge the backup cell, and the eco-friendly design means no disposable batteries. One charge lasts over a year.
Customized Passcode Access
Permanent
Code
for
Families
One-time
Code
for Guest
& Friends
Scheduled
Code
for Service/
Maintenance
Prevent
Unauthorized
Access
The keypad, fingerprint, and palm sensor lock automatically disables after multiple incorrect attempts, stopping intruders from trying again.
Secure PIN Entry
Add random numbers before or after your PIN so no one can guess your code by looking over your shoulder.
Built-In Doorbell
A seamless 2-in-1 smart lock and doorbell for easy access and reliable, complete protection.
Emergency Power Supply
When your battery runs out you can use your phone for reverse charging or power bank for emergency power.
* Phone and power bank must support USB-C reverse charging functionelty.
Find Your Smart Lock
Tapo DL130 |
Tapo DL110 |
Tapo DL100 |
|
|---|---|---|---|
| Unlock Methods | |||
| Palm | ✓ | ||
| Fingerprint | ✓ | ✓ | |
| Keypad | ✓ | ✓ | ✓ |
| App (Wi-Fi/Bluetooth) | ✓ | ✓ | ✓ |
| Physical Key | ✓ | ✓ | ✓ |
| Third-Party Control | ✓ | ✓ | ✓ |
| Battery Life | up to 1 year | up to 1 year | up to 7 months |
| BHMA Grade | Grade 2 | Grade 2 | Grade 3 |
| Weatherproof (External unit only) |
IP65 | IP65 | IP54 |
| Auto Lock | Door Sensor | Timer | Timer |
| Third-Party Compatibility |
Amazon, Google Assistant, SmartThings |
Amazon, Google Assistant, SmartThings |
Amazon, Google Assistant, SmartThings |
| Buy Now → |
FAQ
What is palm vein recognition?
Palm vein recognition uses near-infrared light to scan the vein patterns beneath the skin of a person's palm. These patterns are unique to each individual, even among identical twins, and remain stable throughout a person's life.
Is palm vein recognition safe?
Palm vein recognition is inherently more secure because it uses liveness detection, ensuring only a real, living hand can be recognized, preventing spoofing attempts. The vein patterns are internal and hidden within the body, making them extremely difficult to copy or counterfeit. It also enables contactless authentication, reducing the risk of physical tampering or residue-based attacks.
How long do Tapo DL130 batteries last?
Tapo DL130 features a dual-battery system. When the main battery pack is removed for charging, it switches to the built-in backup battery for power. Once the main battery is reinstalled after charging, it will automatically recharge the backup battery. As long as the main battery is charged in time, it can achieve virtually uninterrupted operation, with each full charge lasting over one year. Actual battery life may vary depending on device settings, router specifications, usage patterns, and environmental factors. Battery performance is based on TP-Link laboratory testing.
Does Tapo DL130 work without Wi-Fi?
Yes, Tapo DL130 supports a Bluetooth-only mode, allowing you to setup and use the device without connecting to Wi-Fi. Even without Wi-Fi, you can still use palm vein, fingerprint, and passcode unlocking methods. You can also unlock the door via the app using Bluetooth when near the lock, making it suitable for no-network or weak-signal environments.
Can I share access with family?
The Tapo app's Device Sharing feature lets you share access to your Tapo Door Locks with family members and other users. Sharing works by sending an invitation to another TP-Link account. You can stop sharing at any time. You can also assign different permission levels, such as Basic or Advanced, to control what shared users can do.
How can I use Tapo DL130 together with my Tapo doorbell?
You need to link your Tapo doorbell with Tapo DL130 first. When a visitor arrives, you can directly lock or unlock the door from either the doorbell call interface or the doorbell live view page. If your doorbell is equipped with a chime, it will also ring when a visitor presses the doorbell button on the DL130.
| Doorbell Ring | Yes |
|---|---|
| Reset | Yes |
| WiFi Mode Select | Yes (Software Control) |
| Type-C Plug in | The battery uses Type-C charging.The external unit includes a Type-C reverse charging cable for emergency power supply. |
| Maximum Fingerprint ID | 100 |
|---|---|
| Maximum Access code | 200 |
| One-time Code | Yes |
| Tapo APP | Yes |
| Emergency Unlock | Yes |
| Menchanical Key | Yes |
| Automatic Locking | Yes |
| Weatherproofing | IP65 |
| BHMA Certification | BHMA Grade 2 |
| Network Connectivity | Connect via Wi-Fi and BLE 5.0 |
|---|---|
| Wireless Connectivity | IEEE 802.11a/b/g/n, 2.4GHz/5GHz Wi-Fi and Bluetooth |
| Protocol | TCP/IP, DHCP, ICMP, DNS, NTP, HTTPS, TCP, UDP |
| Transmission Rate | 11b: 11 Mbps11g: 54 Mbps11n: 72.2 Mbps |
| Security | 128-bit AES Encryption with SSL/TLSWPA/WPA2-PSK/WPA3 |
|---|---|
| Input Voltage | Battery Pack Adapter Input: 100-240 V, 50/60 Hz |
|---|---|
| Output Voltage | Battery Pack Adapter Output: 4.2 V |
| DC Power Connector Size | Type C |
| Power Cord Length | 0.5m |
| Typical Power Consumption | 1.28 mW (WiFi Mode Standby) |
| Maximum Power Consumption | 1872 mW |
| Certification | FCC,RoHS,BHMA，CEC,NRCan,DOE,MSDS,UN38.3,IP65, Lithium batteries, permanent magnets |
|---|---|
| Smart Integration | Google Assistant, Alexa, SmartThings |
| Weather Resistance | IP65(Exterior Assembly)Not weatherproofing(Interior Assembly) |
| System Requirements | Tapo App: iOS 11 or higher, Andriod 5.0 or higher |
| Mounting Options | door-Mounted |
| Operating Temperature | -30℃~70℃(Exterior Assembly) (-22 ℉ ~158 ℉ )-10℃~55℃(interior Assembly) (41 ℉ ~131 ℉ ) |
| Storage Temperature | -40℃～70℃ (-40 ℉ ~ 158 ℉ ) |
| Operating Humidity | 10～90%RH |
| Storage Humidity | 0～90%RH |
| Charging Temperature | 0~45℃ (32 °F ~ 113 °F) |
| Screw Size | Machine Screw：M4*7.5/3PCSSelf-tapping Screw：ST4*20/1PCSMachine Screw：M5*10/2PCS |
| Weight | Net weight: 1.052 KGGross weight: 2.407KG |
| Package Content | Tapo DL130 Door Lock X1Installation Plate X1Latch Bolt X1Door Sensor X1Battery Pack X1Strike Plate & Dust Box X1Silicone Cover X1Keys X2Installation Screws X6Power Cable (1.64 ft) X1Installation Cards and Stickers X2Quick Start Guide X1 |
| Dimensions( W X D X H ) | Exterior Assembly:171*67.9*32.6(mm)Interior Assembly:197.9*72.8*54(mm) |
1. Battery life is based on TP-Link laboratory tests, assuming 20 unlocks per day with estimated durations up to 1 year in Wi-Fi mode, depending on settings, router specifications, usage, and environmental factors.
2. Actual battery life may vary due to device.
