M7005 Setup Guide

Model: M7005

Welcome! To ensure equal access for all users, we offer this setup guide. This guide is designed to meet accessibility needs. It will introduce the appearance of your Mobile Wi-Fi and then guide you through the initial configuration process.

Our tpMiFi app and web management page also offer accessibility features, such as increasing page contrast, switching to landscape mode and increasing font size. You can enable them during setup to make it much easier to set up your device and adjust settings! For more accessibility guidance, refer to Accessibility Support.

Note: For some models, Accessibility features will be supported by subsequent firmware upgrades.

Step 1. Know about your Mobile Wi-Fi

This section introduces the package content and product appearance.

1. Package Contents

Mobile Wi-Fi: This small device is usually rectangular and smooth, featuring buttons, a screen or indicator lights.

USB Cable: The cable has a flat nearly rectangular connector on one end and a small flat connector on another. For connecting to the USB port for charging.

2. Product Appearance

Facing the front side of the product, there is a physical button on the right of the top side, which is the Power Button.

There are 3 LED indicators in the lower right corner of the front side, indicating the working status.

The USB port is on the middle of the bottom side, which is a small and flat port.

The Nano SIM Card Slot is on the left of the USB port. It has a small rectangular rubber cover, which feels different from the material of the other places on the bottom side.

The Reset Button is on the left of the Nano SIM Card Slot. It is a very tiny recessed button that requires a pin to press. With the Mobile Wi-Fi powered on, use a pin to press and hold the Reset button for more than 5 seconds to reset the mobile Wi-Fi to its factory default settings.

Turn the product upside down, on the back side, there is slightly recessed product label. The label contains the serial number, MAC address, IMEI, SSID and Wireless Password.

Step 2. Install the SIM Card

1. Position the SIM card slot on the left of the bottom side to facilitate the next steps. Lift the rubber cover from the left. Insert your SIM card into the Nano SIM Card Slot with the gold contacts facing down until you feel a click. Replace the rubber cover.

2. Scan the barcodes on the product label. Note down the 8-digit Wireless Password and the 12-digit MAC address. If the information you scanned is not 8-digit or 12-digit, please scan a few more times.

Step 3. Connect to the Internet

1. Press and hold the Power button on the right for more than 5 seconds to power on the Mobile Wi-Fi.

2. Connect your smart device to the Mobile Wi-Fi Network TP-Link_XXXX or TP-Link_XXXX_5G. XXXX is the last 4 digits of the MAC address you mark down.

3. To manage the Mobile Wi-Fi easily, you can download the tpMiFi app by scanning the QR code below. Or scan the QR code for APP on the braille card if it has one.

Scan the QR Code to download the APP

Need Help?

If the problem still exists or you need more Accessibility Support, contact us at https://www.tp-link.com/support/ for further assistance.
