8-Port 10/100Mbps Desktop Switch with 4-Port PoE+

  • 8× 10/100 Mbps RJ45 ports
  • 4× PoE+ ports transfer data and power on individual cables
  • Works with IEEE 802.3af/at compliant PDs
  • Supports PoE Power up to 30 W for each PoE port
  • Supports PoE Power up to 66 W for all PoE ports*
  • Up to 250m data and power transmitting range under Extend Mode**
  • Priority Mode ensures high priority of ports 1–2 to guarantee the quality of sensitive application
  • PoE Auto Recovery guarantees stable operation of PoE devices by automatically rebooting the dropped or unresponsive PD devices
  • Fanless Design reduces power consumption and works silently in its location
  • Plug and play with no configuration required

Learn more about TP-Link PoE technology >

  • Introducing TP-Link PoE Switches

  • What is TL-SF1008P?

Professional High-Power 8-Port Unmanaged Switch with 4 PoE+ Ports

Plug and Play, with PoE Transmission for Surveillance up to 250 m

TL-SF1008P

  •

    66 W PoE Budget*

  •

    Plug and Play

  •

    Transmission Distance up to 250 m**

  •

    One-Click Priority Mode

  •

    PoE Auto Recovery

  •

    Intelligent Power Management

  •

    Durable Metal Casing

  •

    Silent Operation

Dedicated 8-Port Switch with 4-Port PoE+ (66 W Budget) for Numerous Applications

Compliance with the 802.3af/at PoE+ standard supports up to 30 W on each PoE port. The total 66 W PoE power budget* for the 4× PoE ports opens up a wide range of applications, such as surveillance for offices, dormitories, and small businesses. It is fully compatible with IP cameras, access points, IP phones, computers, printers, and more.

Network Video Recorder
Computer
Printer
Surveillance
IP Camera
Conference Calls
IP Phone
Wi-Fi Coverage
Access Points
Power over Ethernet
TL-SF1008P
Router
Internet
4 PoE+ Ports
Up to 30 W on Each Port
Total 66 W Power Budget

Plug and Play, No Configuration Required

  • 1
    Plug In

  • 2
    Connect Devices
    Internet
    IP Phone
    IP Camera
    Access Points
    Router
    TL-SF1008P
  • 3
    Enjoy


Dedicated Design for IP Surveillance
—Up to 250 m Transmissions

With extend mode, the PoE transmission distance reaches up to 250 m*—perfect for IP Camera deployment in large areas.

*The speed of the ports in extend mode will downgrade to 10 Mbps. The actual transmission distance may vary due to power consumption of PoE-powered devices or the cable quality and type.

Extend Mode Button
TL-SF1008P ( Extend Mode On )
Up to 250 m
Extended is 10 Mbps/port
×4
Up to Four IP Cameras
TL-SF1008P ( Extend Mode Off )
100 m
Default is 100 Mbps/port
×4
Up to Four IP Cameras
IP Cameras
IP Cameras
Priority Mode Button


Priority Video
Quality Guaranteed

Quality of sensitive applications like video monitoring in critical business areas is guaranteed by offering higher priority options for ports 1–2 when one-touch Priority Mode is on.

System Self-Healing
with PoE Auto Recovery

The switch automatically detects and reboots the PD devices, such as cameras and APs, when they fall offline or go unresponsive, guaranteeing the stable operation of PoE-connected devices, without need for manual monitoring and restart.


Priority Mode Button
IP Camera
IP Camera
PoE Auto Recovery
Power overload
66W
Intelligent Power Management
Intelligent power supply
66W
19W
19W
19W
19W
19W
19W
19W


Intelligent Power Management

When total power consumption exceeds 66 W, the intelligent power management will cut the lower priority port power. This ensures the high priority port’s power supply and protects the device from power overload. It also automatically detects and provides the required power for your PoE devices while protecting your PoE and non-PoE equipment from being damaged.

High-Quality Metal
27mm
171mm
98mm

Durable Metal Casing

The interior components of TL-SF1008P are protected by high-quality metal casing to ensure a long product life. Having passed an array of stringent reliability tests, TL-SF1008P delivers switching performance you can depend on.

  •
    Compact Desktop Design
  •
    Wall-Mounting
  •
    Fanless Design
HARDWARE FEATURES
Interface • 8× 10/100 Mbps RJ45 Ports (4× 10/100 Mbps 802.3af/at PoE+ ports)
• AUTO Negotiation
• AUTO MDI/MDIX
Network Media • 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
• EIA/TIA-568 100Ω STP (maximum 100m)
• 100BASE-TX: UTP category 5, 5e cable (maximum 100m)
• EIA/TIA-568 100Ω STP (maximum 100m)
Fan Quantity Fanless
Physical Security Lock Yes
External Power Supply External Power Adapter (Output: 53.5 V DC / 1.31 A)
Packet Forwarding Rate 1.1904 Mpps
PoE Ports (RJ45) • Standard: 802.3 af/at compliant
• PoE Ports: Ports 1–4
• Power Supply: 66 W
Mac Address Table 2K
Jumbo Frame 2 KB
Switching Capacity 1.6 Gbps
Dimensions ( W x D x H ) 6.7 × 3.9 × 1.1 in (171 × 98 × 27 mm)
Max Power Consumption 2.27 W (220 V/ 50 Hz. no PD connected)
75.33 W (220 V/ 50 Hz. with 66 W PD connected)
Max Heat Dissipation 7.74 BTU/h(no PD connected)
256.88 BTU/h(with 66 W PD connected)
SOFTWARE FEATURES
Transmission Method Store-And-Forward
Advanced Functions Extend Mode Button (Ports 1–4)
Priority Mode Button (Ports 1–2)
PoE Auto Recovery Button (Ports 1–4)
Mac Address Auto-Learning and Auto-Aging
OTHERS
Certification FCC, CE, RoHS
Package Contents TL-SF1008P, Power Adapter, Installation Guide, Rubber Feet
Environment Operating Temperature: 0–40 ℃ (32–104 ℉)
Storage Temperature: -40–70 ℃ (-40–158 ℉)
Operating Humidity: 10–90% RH non-condensing
Storage Humidity: 5–90% RH non-condensing

*PoE budget calculations are based on laboratory testing. Actual PoE power budget is not guaranteed and will vary as a result of client limitations and environmental factors.

**The speed of the ports in extend mode will downgrade to 10 Mbps. The actual transmission distance may vary due to power consumption of PoE-powered devices or the cable quality and type.
