AC750 Wireless Dual Band Gigabit VDSL2 Modem Router
- With Ethernet WAN and USB ports, VR200 is fully compatible with VDSL2/ADSL2+/ADSL2/ADSL standard, fiber/cable access and 3G/4G USB dongles
- Superfast Wi-Fi speed up to 300Mbps on 2.4GHz and 433Mbps on 5GHz for amazing wireless experience
- 3 dual band detachable antennas provide excellent Omni-directional wireless coverage and reliability
- The beamforming technology improves wireless range and performance on 2.4GHz
Superfast Broadband Speeds and Fast Wi-Fi Speeds
The Archer VR200 features superfast broadband speeds of up to 100Mbps and supports VDSL2, as well as backward compatibility with ADSL2+/ADSL2/ADSL.
The modem router exploits the full potential of VDSL broadband connections to deliver Wi-Fi speeds of up to 750Mbps (300Mbps on 2.4 GHz and 433Mbps on 5GHz). Also, by using two dedicated networks, it reduces wireless signal interference.
The Archer VR200 is an integrated DSL modem router that works with any kind of Internet connection, including VDSL, VDSL2, ADSL, ADSL2, and ADSL2+.
With the Gigabit Ethernet WAN option, the Archer VR200 can also be used with any fiber broadband or cable modem with an Ethernet output.
While the DSL and Ethernet WAN inputs provide universal compatibility with any Internet service, both of the USB ports also support 3G/4G dongle connections. This universal router gives you the flexibility to keep your current ISP or change ISPs in the future, without compromising wireless performance.
As a complete integrated modem router, the Archer VR200 provides versatile connectivity options including VDSL/ADSL, fiber/cable and 3G/4G USB dongle connections. This makes it easier when users need to choose among different Internet service providers when necessary.
Better Coverage and a More Stable Connection
Three external antennas help the Archer VR200 provide stable coverage throughout your entire home and property. Advanced Beamforming technology automatically locates wireless devices and forms targeted, highly efficient wireless connections.
Fast USB Sharing
With USB 2.0 ports, you can easily access and share a local printer, a local network drive, or a remote FTP server. Storing, accessing, and sharing files and media has never been easier.
For added connection versatility, both USB ports support 3G/4G dongles, so you can stay connected without missing a beat.
Dual USB 2.0 ports make it easy to share files, photos, music, and video across your network. Both USB ports support 3G/4G dongles.
Gigabit Wired Connection
With four built-in Gigabit Ethernet ports, the Archer VR200 is capable of providing the stable, ultra-fast wired connections that you need to ensure lag-free gaming and uninterrupted HD video streaming.
With four built-in Gigabit Ethernet ports, the Archer VR200 is capable of providing the stable, ultra-fast wired connections.
The sophisticated design enhances every home. Its gentle curves, excellent crafting and remarkable quality exudes style and elegance without compromising on performance.
The gentle curves, excellent crafting and remarkable quality exudes style and elegance without compromising on performance.
Easy Setup and Use
The Archer VR200's powerful web interface allows it to be set up and configured in a matter of minutes. The intuitive design allows users to easily monitor and personalize settings for a wide range of functions including guest networks and parental controls.
Powerful web interface allows it to be set up and configured in a matter of minutes. The intuitive design allows users to easily monitor and personalize settings.Learn more about intuitive web interface >
|Arabirim||3 10/100/1000Mbps RJ45 LAN Ports
1 10/100/1000Mbps RJ45
1 RJ11 Port
2 USB 2.0 Port
|Buton||WPS Button, LED Button, Wireless On/Off Button, Power On/Off Button|
|Harici Güç Kaynağı||12V/2A|
|IEEE Standartları||IEEE 802.3, IEEE 802.3u, 802.3ab|
|VDSL2 Standartları||ITU-T G.993.2, Up to 30a profile (POTS)
ITU-T G.993.5 (G.vector)
ITU-T G.998.4 (G.INP）
|ADSL Standartları||Full-rate ANSI T1.413 Issue 2
ITU-T G.994.1 (G.hs)
|ADSL2 Standartları||ITU-T G.992.3 (G.DMT.bis)
ITU-T G.992.4 (G.lite.bis)
|ADSL2+ Standartları||ITU-T G.992.5|
|Boyutlar ( W X D X H )||9.6 x 7.1 x 3.5 in. (245 x 181 x 90 mm)|
|Anten Tipi||3 external detachable dual band antennas (RP-SMA)|
|Anten Kazancı||3 x 2dBi for 2.4GHz and 1x 3dBi for 5GHz|
|Kablosuz Standartlar||IEEE 802.11a/n/ac 5GHz, IEEE 802.11b/g/n 2.4GHz|
|Frekans||2.4GHz and 5GHz|
|Bağlantı Hızı||433Mbps at 5GHz, 300Mbps at 2.4GHz|
|Kablosuz Fonksiyonlar||Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless, Statistics|
|Kablosuz Güvenlik||64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA-PSK2 encryptions, Wireless MAC Filtering|
|Kablosuz Takvim||Support 2.4GHz and 5GHz Wireless Schedule|
|Quality of Service||ATM QoS, Traffic Control(IP QoS)|
|Güvenlik||NAT Firewall, Access Control, MAC / IP / URL Filtering, Denial of Service (DoS), SYN Flooding, Ping of Death, IP and MAC Address Binding|
|Çalışma Modları||VDSL/ADSL Modem Router, Wireless Router|
|Yönetim||Web Based Configuration(HTTP), Remote management, command Line Interface, SSL for TR-069, SNMP v1/2c, Web Based Firmware Upgrade, Diagnostic Tools|
|DHCP||Server, Client, DHCP Client List, Address Reservation, DHCP Relay|
|Port Yönlendirme||Virtual Server, Port Triggering, DMZ, ALG, UPnP|
|Dinamik DNS||DynDns, NO-IP|
|VPN Pass-Through||PPTP, L2TP, IPSec Passthrough|
|Protokoller||Supports IPv4 and IPv6|
|ATM/PPP Protokolleri||ATM Forum UNI3.1/4.0, PPP over ATM (RFC 2364),
PPP over Ethernet (RFC2516), IPoA (RFC1577/2225), MER\IPoE (RFC 1483 Routed), Bridge (RFC1483 Bridge), PVC – Up to 8 PVCs
|Gelişmiş Fonksiyonlar||Parental Control, Network Address Translation(NAT), Port Mapping(Grouping), Static Routing,
RIP v1/v2(optional), DNS Relay, DDNS, IGMP V1/V2/V3
|USB Paylaşım||Support Samba(Storage)/FTP Server/Media Server/Printer Server, 3G/4G Modem|
|Misafir Ağ||2.4GHz guest network x 1, 5GHz guest network x 1|
|IPSec VPN||Supports up to 10 IPSec VPN tunnels|
|Sertifika||CE, FCC, RCM, RoHS|
|Paket İçeriği||AC750 Wireless Dual Band Gigabit VDSL2 Modem Router Archer VR200
RJ11 DSL Cable
RJ45 Ethernet Cable
Quick Installation Guide
|Sistem Gereksinimleri||Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1, MAC OS,NetWare, UNIX or Linux
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser
Cable or DSL Modem
Subscription with an Internet Service Provider (for Internet access)
|Ortam||Operating Temperature: 0℃~40℃ (32℉ ~104℉)
Storage Temperature: -40℃~70℃ (-40℉ ~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
