16-Port Gigabit Easy Smart Switch

  • 16 10/100/1000Mbps RJ45 ports
  • Plug and play, with no configuration required
  • Durable metal casing of superior quality and professional appearance
  • Intelligent management via a web user interface and downloadable utility
  • Green technology reduces power consumption

Increase Your Network Speed and Save Energy

16-Port Gigabit Desktop Switch

TL-SG116E

Link Your Devices, Create Convenient Business

The 16-Port Gigabit Easy Smart Desktop Switch provides an easy way to expand your wired network. Deal with your business quickly and easily, whether you are at home or in the office.

Office Network
Home Network

Easy to Use

  • 1Plug In


  • 2Connect The Devices

    IPTV Printer Computer Internet Router
  • 3Enjoy



Gigabit Ports for Maximum Speed

16 non-blocking 10/100/1,000 Mbps ports make it possible to transfer large, bandwidth-intensive files with no interference.

More Features,More Choices

  • QoS for a Lag-Free Experience

    Ensures smooth traffic for latency sensitive applications, such as voice and video

  • IGMP Snooping for Multicast Optimization

    Ensures a better network experience, especially for applications like IPTV, by optimizing multimedia traffic delivery.

  • VLAN for Security

    Helps to create network with higher security and better overall performance by dividing network into smaller groups

Management Made Easy

TL-SG116E offers network monitoring for users to observe traffic behavior. Through its web-based user interface and management utility, the TL-SG116E offers a variety of useful features, including network monitoring, traffic prioritization, and enhanced QoS.

Management Utility User Interface

Durable Metal Casing

The interior components of TL-SG116E are protected by high-quality metal casing to ensure a long product life. Having passed an array of stringent reliability tests, TL-SG116E delivers switching performance you can depend on.

Compact Desktop Design Wall-Mounting Fanless Design
High-quality metal 25.4mm 286mm 111.7mm

Go Green with Your Ethernet

TP-Link’s latest generation of Easy Smart Switches make use of innovative energy-saving technologies. Power consumption automatically adjusts according to link status and cable length, allowing you to expand your network while minimizing your carbon footprint. Save the planet and lower your energy bills — it’s a win-win!

energy
conservation
HARDWARE FEATURES
Standards and Protocols IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1q, IEEE 802.1p
Interface 16 10/100/1000Mbps RJ45 Ports
AUTO Negotiation/AUTO MDI/MDIX
Network Media 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
Fan Quantity Fanless
Power Supply External Power Adapter(Output: 12VDC/1.0A)
Dimensions ( W x D x H ) 11.3 × 4.4 × 1.0 in. (286 × 111.7 × 25.4 mm)
Max Power Consumption 9.19W(220V/50Hz)
Max Heat Dissipation 31.36BTU/h
PERFORMANCE
Switching Capacity 32Gbps
Packet Forwarding Rate 23.81Mpps
MAC Address Table 8K
Packet Buffer Memory 4.1Mb
Jumbo Frame 9KB
SOFTWARE FEATURES
Quality of Service Support Port-based/802.1p/DSCP priority
Support 4 priority queues
Rate Limit
Storm Control
L2 Features IGMP Snooping V1/V2/V3
Static Link Aggregation
Port Mirroring
Cable Diagnostics
Loop Prevention
VLAN Supports up to 32 VLANs simultaneously (out of 4K VLAN IDs)
MTU/Port/Tag VLAN
Transmission Method Store-And-Forward
OTHERS
Certification FCC, CE, RoHS
Package Contents TL-SG116E
Power Cord
Installation Guide
Rubber Feet
System Requirements Microsoft® Windows® for running Utility
Environment Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
