RC120-F5
Coming SoonAC750 Wi-Fi Range Extender
- Boosts wireless signal to previously unreachable or hard-to-wire areas flawlessly
- Compatible with 802.11 b/g/n and 802.11ac Wi-Fi devices
- Dual band speeds up to 750Mbps
- Miniature size and wall-mounted design make it easy to deploy and move flexibly
- Ethernet port allows the Extender to function as a wireless adapter to connect wired devices
Boost Your Wi-Fi Network to Cover hard-to-reach Areas
Place the RC120-F5 between your wireless router and wireless devices, expanding Wi-Fi coverage while eliminating Wi-Fi dead zones. Enjoy a seamless wireless network throughout your home or office. The dual bands Wi-Fi up to 750Mbps not only help extend to 2,000 sq.ft. (185 m2), but also make good use of your high ISP speed — ideal for HD video streaming, online gaming and other bandwidth-intensive tasks.
- RC120-F5 Coverage
- Router Coverage
- Easily extend your Wi-Fi range with
the push of a button - Existing router
AC750 Wi-Fi for Compatible Connections
The RC120-F5’s Wireless AC technology create stronger Wi-Fi
connections across your home. Work with any standard
router or access point, making it convenient to provide wide, non-droppingDual Band Wi-Fi to multiple devices.
Backwards compatible
802.11 a/b/g/n
One Key Connection
Press the WPS button on your router and RE button on your RC120-F5 within 2 minutes to easily connect to the network. Once connected with an existing router, you can simply relocate the RC120-F5 at any location for the best signal strength.
Smart Signal Indicator
Smart signal lights indicate the signal strength received from the existing router. Read the lights to find the best location for your RC120-F5.
- Good connection
- Too far away from the router
- No connection
Entertainment Adapter
With an Ethernet port, RC120-F5 can function as a wireless adapter to connect wired devices like desktop, gaming consoles, Blu-ray® players, and Internet TVs. At the same time, the device can share the wireless network as well.
- Phone
- Pad
- Laptop
- Game Console
- Desktop
- TV
Dedicated to Networking for over 20 years
Dedicated provider of networking products for over 20 years, with industry-leading professionalism and
time-proven reliability.
HARDWARE FEATURES | |
---|---|
Plug Type | EU, UK, US, AU |
Standards and Protocols | IEEE802.11ac,IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
Interface | 1 x 10/100M Ethernet Port (RJ45) |
Button | RE (Range Extender) Button, Reset Button |
Power Consumption | About 6.5W |
Dimensions ( W x D x H ) | 4.3x 2.6 x 3.0in. (110.0 x 65.8 x 75.2mm) |
Antenna | 3 x internal |
WIRELESS FEATURES | |
---|---|
Frequency | 2.4GHz & 5GHz |
Signal Rate | 5GHz:Up to 433Mbps 2.4GHz:Up to 300Mpbs |
Reception Sensitivity | 2.4G: 270M: -70dBm@10% PER 130M: -70dBm@10% PER 108M: -73dBm@10% PER 54M: -75dBm@10% PER 11M: -86dBm@8% PER 6M: -92dBm@10% PER 1M: -94dBm@8% PER 5G: 390M: -60dBm@10% PER 29.3M: -83dBm@10% PER 180M: -64dBm@10% PER 13.5M: -87dBm@10% PER 78M: -68dBm@10% PER 6.5M: -90dBm@10% PER 54M: -75dBm@10% PER 6M:-90dBm@10% PER |
Transmit Power | < 20 dBm (EIRP) |
Wireless Modes | Range Extender |
Wireless Functions | WMM (Wi-Fi Multimedia) Wireless Statistic Domain Login Function |
Wireless Security | 64/128/152-bit WEP WPA-PSK / WPA2-PSK |
OTHERS | |
---|---|
Certification | CE, FCC, RoHS |
Package Contents | AC750 Wi-Fi Range Extender RC120-F5 Quick Installation Guide |
System Requirements | Microsoft® Windows® 98SE, NT, 2000, XP, Vista or Windows 7, 8, 10, Mac® OS, NetWare®, UNIX® or Linux. |
Environment | Operating Temperature: 0°C~40°C (32°F~104°F) Storage Temperature: -40°C~70°C (-40°F~158°F) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specifications. Actual wireless data throughput and wireless coverage are not guaranteed and will vary as a result of 1) environmental factors, including building materials, physical objects, and obstacles, 2) network conditions, including local interference, volume and density of traffic, product location, network complexity, and network overhead, and 3) client limitations, including rated performance, location, connection quality, and client condition.
The product may not be compatible with routers or gateways with firmware that has been altered, is based on open source programs, or is non-standard or outdated.
