300Mbps Wireless N Range Extender
TL-WA830RE

Highlights:

  • 300Mbps wireless speed ideal for smooth HD video, music streaming and online gaming
  • Two MIMO antennas greatly extend your existing wireless coverage to eliminate “dead zones”
  • Easily extend wireless coverage only in a few seconds at a push of Range Extender button
  • Working seamlessly with all 802.11b/g/n devices
  • Bundled Easy Setup Assistant helps set up the connection step by step in minutes

Overview

What This Product Does

TP-LINK’s TL-WA830RE 300Mbps Wireless N Range Extender is designed to extend the coverage and improve the signal strength of an existing wireless network to eliminate “dead zones”. Combined with leading wireless N technologies, superior security and wider compatibility, TL-WA830RE makes it a secure high speed solution that can help you keep an existing wireless network unchanged and vastly improve the network’s coverage, giving you the freedom to enjoy Internet anywhere uninterruptedly in large areas such as homes, hotels or small offices without worrying about coverage limits.

Wireless N - Speed & Range

Adopting IEEE 802.11n advanced MIMO (Multi Input Multi Output) technology, TL-WA830RE simultaneously works through two antennas to Tx and Rx to overcome the interference and signal degradation when traveling long distances or through physical barriers in a small office or a large apartment, resulting in an incredible improvement in the wireless performance, even in a steel-and-concrete building. Above all, you could easily pick up the wireless network during long-distance connection where legacy 11g products may not!

Incredible Wireless Extension

TL-WA830RE is designed to select “Range Extender” as the default wireless mode, working as a “relay station” to repeat the wireless signal flawlessly to longer distance where is previously outside the coverage of the existing wireless network. Due to leading Wireless N technologies, it can overcome obstacles and enhance overall network signal quality, then providing the same reliable network connecting as wired network. Better still, TL-WA830RE can also work in the conventional AP mode, accessing the Internet via ADSL/Cable modem and linking the wireless and wired network together.

One Button for Connection

TL-WA830RE features Range Extender Button that allows users to setup the wireless connection simply by pressing the "Range Extender" button.

Full Compatible with 802.11b/g/n Devices

TP-LINK Wireless N Range Extender TL-WA830RE is fully compatible with all IEEE 802.11b/g/n devices, including routers, gateways, access points and adapters. Specifically, it can not only maximize performance with 802.11n products, but also achieve full capacity when linking with 802.11b/g products. Therefore you can make full use of all your existing wireless devices without any replacement cost, and even upgrade your wireless network off to Wireless N age.

WPA / WPA2 Encryptions - Advanced Security

As for the security of Wi-Fi connection, WEP encryption has been no longer the strongest and safest guards for outside threats. TL-WA830RE provides WPA/WPA2 encryptions that are created by the Wi-Fi Alliance industry group, preventing the wireless network from outside threats.

Features

  • 300Mbps wireless speed ideal for smooth HD video, music streaming and online gaming
  • MIMO™ & CCA™ technology provides robust high-bandwidth wireless performance while automatically avoiding channel conflict
  • Range Extender mode greatly extends your existing wireless coverage to eliminate “dead zones”
  • AP mode helps establish a scalable high-speed wireless network with wide coverage
  • Easily extend wireless coverage only in a few seconds at a push of Range Extender button
  • Supports Wi-Fi Multimedia (WMM) assures the quality of VoIP and multimedia streaming
  • Full compatible with all IEEE 802.11b/g/n products
  • Advanced 64/128/152-bit WEP, WPA-PSK / WPA2-PSK encryptions protect your network from security threats
  • Bundled utility provides quick & hassle free connections to routers or AP
  • External detachable antennas allow for better alignment and stronger antenna upgrades

Specifications

HARDWARE FEATURES
InterfaceOne 10/100M Ethernet Port(RJ45)
ButtonRange Extender Button
Reset Button
Power On/Off Button
External Power Supply9V-0.6A
Wireless StandardsIEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Antenna2*5dBi Detachable Omni Directional (RP-SMA)
Dimensions ( W x D x H )7.2*5.0*1.4 in.(181.5*125.7*36.2 mm)
Power Consumption3W
WIRELESS FEATURES
Frequency2.4~2.4835GHz
Signal Rate11n: Up to 300Mbps(dynamic)
11g: Up to 54Mbps(dynamic)
11b: Up to 11Mbps(dynamic)
EIRP< 20 dBm (EIRP)
Reception Sensitivity270M: -68dBm@10% PER
130M: -68dBm@10% PER
108M: -68dBm@10% PER
54M: -68dBm@10% PER
11M: -85dBm@8% PER
6M: -88dBm@10% PER
1M: -90dBm@8% PER
Wireless ModesRange Extender, AP Mode
Wireless FunctionsWMM(Wi-Fi Multimedia)
Wireless MAC Address Filtering
Enable/Disable Wireless Radio
Enable/Disable Wireless SSID Broadcast
AP Isolation
Wireless Statistic
Domain Login Function
Wireless Security64/128/152-bit WEP
WPA-PSK / WPA2-PSK
OTHERS
CertificationCE, FCC, RoHS
Package ContentsWireless N Range Extender TL-WA830RE
2 Detachable Omni directional antennas
RJ-45 Ethernet Cable
Power supply unit
Resource CD
Quick Installation Guide
System RequirementsMicrosoft Windows 98SE, NT, 2000, XP, Vista, Windows 7, Windows 8, Mac OS, NetWare, UNIX or Linux
EnvironmentOperating Temperature: 0°C~40°C (32°F~104°F)
Storage Temperature: -40°C~70°C (-40°F~158°F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing

Download

Some official firmware of TP-LINK products can be replaced by the third party firmware such as DD-WRT. TP-LINK does not provide technical support and does not guarantee the performance and stability of third party firmware. Damage to the product as a result of using third party firmware will void the product's warranty.
